Romex 28828223 Building Wire, 12 AWG Wire, 2 -Conductor, 100 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

Romex

Romex 28828223 Building Wire, 12 AWG Wire, 2 -Conductor, 100 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

Romex 28828223 Building Wire, 12 AWG Wire, 2 -Conductor, 100 ft L, Copper Conductor, PVC Insulation, Nylon Sheath
  • Conductor Insulation: PVC
  • Conductor Material: Copper
  • Current Rating: 20 A
  • Length: 100 ft
  • Number of Conductors: 2
  • Model #: 28828255
  • UPC #: 032886263095
  • SKU: 88626309

Availability

Product Details

Southwire® Romex® brand SIMpull® NM-B cable is manufactured as two, three or four conductor cable, with a bare ground wire. Copper conductors are annealed (soft) copper. Stranded conductors are compressed stranded. Conductor insulation is 90 deg C rated polyvinyl chloride (PVC), nylon jacketed. Romex® brand SIMpull® NM-B cable is designed for easier pulling, resulting in easier installation. The cable jacket is color-coded for quick size identification.

Item Specifications

Conductor InsulationPVC
Conductor MaterialCopper
Current Rating20 A
Length100 ft
Number of Conductors2
Operating Temperature<90 deg C
Sheath ColorYellow
Sheath Diameter418 x 179 mil
Sheath MaterialNylon
Stranded/SolidSolid
Strands per Conductor1
Suitable forOutlets and Switch
TypeNM-B
Voltage Rating600 V
Wire Size12 AWG
